Mercruiser 5.7L 350 Horizon Inboard V-Drive 300hp

The ideal repower for your inboard cruiser up to 34'. A quality fuel injected inboard engine to replace any make of 5.7L, 6.0L, 6.2L, or 7.4L

  • V-drive and In-Line engines available to fit any installation.
  • CARB & EPA compliant
$15,950.99
SKU
F&IMOD-8M0136297
Part number
  • 8M0136297
HP / kW @ flywheel
  • 300 / 224
Full throttle range
  • 4400 - 4800
Engine type
  • Quicksilver Iron Heads using screw in rocker studs, black x-valves and hardened valve seats
Displacement (CID/L)
  • 350 CID (5.7L)
Bore and stroke
  • 4.00” x 3.48” (102mm x 88mm)
Compression ratio
  •  9.4:1 with cast alloy Pistons
Fuel requirement
  • 87 Octane (R+M)/2
Fuel delivery system
  • MPI w/ Gen II cool fuel
 Induction system
  •  2-piece long runner intake with 75mm throttle body
Ignition system
  •  Crank fired high voltage switch w/ knock control
Charging system
  •  65 Amp / 917 Watt Alternator
Water drain system
  •  single point air-actuated water drain with flush port
Exhaust system
  •  Iron Manifold with dry-Joint Exhaust manifold
Cooling system
  •  full closed cooling system - manifolds included
Accessory drive system
  • Serpentine Belt
Lubrication system
  •  High Flow Oil Pump
Recommended oil
  • SAE 25-40 NMMA Certified FC-W Synthetic Blend
Audio warning system
  •  Oil Pressure, Coolant Temperature, Transmission temperature, water temperature
Compatible Transmissions
  • ZF 63A, ZF 63IV, ZF 80A, VD 5000A, 5000V, VD 72C, ZF 63F
Dimensions (L x W x H)
  • 43” x 30” x 22” (1092mm x 740mm x 559mm)
Weight (engine only)
  • 980 lbs.
Boat harness type
  • 10-pin
More Information
Price $15,950.99
Condition New
Brand Mercruiser
Liters 5.7L
Cubic In. 350ci
Horsepower 300hp
Engine Configuration Complete
Fuel Type Gas
Fuel System MPI
Rear Main 1pc Rear Main
Drive Application Sterndrive, Direct Inboard, V-Drive
Engine Rotation Standard Rotation
